ISOLO PRIME - Winds Wireless System
Description
A compact and simple to use wireless microphone that features cutting-edge technology. Add extra texture to your sound with one of the eight built-in effects! Compatible with most wind instruments.
Manual
Overview
Every last detail got first priority
ISOLO was where Clodvocal began. By integrating wireless and audio technology, Cloudvocal completely redefined recording and live performance.We are here to improve everything related to sound. Just as musicians practice to achieve perfection, Cloudvocal never stops practicing our art. Our goal was to add studiograde sound quality to this compact, intuitive device. We achieve it with ISOLO PRIME.
Sound Demo
The all-in-one wireless system
ISOLO PRIME is the advanced system designed for wind instruments so that players can enjoy studio grade sound quality as well as mobility. By integrating essential audio functions and built-in effects, it guarantees your audience an exceptional performance, anytime anywhere.
Features

Cardioid condenser capsule, studio sound where ever you are
Cloudvocal took inspiration form the studio mics to recreate the same resonance details. The mic is designed to capture the strong dynamic without compression nor distortion while cardioid pattern prevents noise bleed in loud situations.
Achieve your desired tone with EQ and 8 built-in effects
When it comes to live performance, tone is not only about your physical control of your instrument but also involves a great part of adjusting EQs and effects. ISOLO PRIME provides effective EQ and specially designed effect algorithms for wind instruments to ensure that you nailed everything from the beginning of your signal chain.


Supports backing tracks and vocal mics, ultra compact for all performances
Besides wireless function, you may need to play backing tracks or need another mic input to interact with the audience. Well, these handy functions are already there for you to use.
One for all, all for one
Specifically designed mounts provide easy and firm installation to most wind instruments. All you need is to attach the mic, adjust gooseneck for the sweet spot then you’re gig ready. Looking for a clip-on alternative? The advanced spring clip is now available and is included in the PRIME package.

Features

Smart wireless transmission
Global standard 2.4GHz transmissionwith one-click pairing.
13 cm extended gooseneck+ Cardioid mic capsule
Extend to the sweetest mic position, prevents unwanted sound bleed in from other directions.
Advanced spring clip
Provides a swift and stablemounting alternative.

8 tailored sound effects
Includes 3 types of reverb, 2 types of delay and 3 types of harmonizer algorithm.
Compact I/O and audiophileop amp
Support up to 3 different audio sources at a time. Audiophile op amp assures all signals to sound great!
Multiple power options
You can use a standard 9V DC adapter as well as power banks with the included power cable.

GAIN
WIRELESS
Wireless mic gain control +/- 6dB
MASTER
Master volume control mute~0dB
EQ
BASS
Bass control of wireless mic signal +/- 6dB @200Hz (shelf type)
TREBLE
Treble control of wireless mic signal +/- 6dB @2000Hz (shelf type)
EFX
EFFECT
① Room reverb ② Hall reverb ③ Arena reverb ④ Delay ⑤ Delay+Reverb ⑥ Shimmer ⑦ Harmonizer A ⑧ Harmonizer
BBLEND
Controls the balance of dry and wet signal
EFX PARM
Rotate to adjust effect detail

① RANGE BOOST
② DI / LINE OUT
- DI OUT : balanced signal via 6.3mm TRS to XLR cable
- LINE OUT: unbalanced signal via 6.3mm TS cable
③ LINE/MIC GAIN
Gain range: 0~40dB
④ LINE/MIC INPUT
Support MIC level to LINE level signal input via 6.3mm TS or TRS cable.
⑤ MUTE PEDAL CONNECTOR
⑧ AUX IN
① RANGE BOOST
② DI / LINE OUT
DI OUT : balanced signal via 6.3mm TRS to XLR cableLINE OUT: unbalanced signal via 6.3mm TS cable
⑤ MUTE PEDAL CONNECTOR
③ LINE/MIC GAIN
Gain range: 0~40dB
④ LINE/MIC INPUT
Support MIC level to LINE level signal input via 6.3mm TS or TRS cable.
⑤ MUTE PEDAL CONNECTOR
⑥ AUX IN
Specs
PRIME Stage Receiver
Dimensions
115mm(L)*75mm(W)*50mm(H)
Net Weight
310g
Transmit bandwidth
2.4GHz global ISM, smart automatic frequency hopping
Working distance
Normal: 15 meters
Range boost on: 15~30 meters
*The distance may alter in different environments.
Power supply
7V-9V DC, 300mA
*5V/2A power banks are recommended for power alternative
Input
6.3mm TRS / TS x1 (for dynamic mic or other line instrument)
3.5 mm TRS x 1 (external audio)
Output
Balanced 6.3mm TRS —> XLR
Unbalanced:6.3mm TRS —> 6.3mm TS
Effect types
①Room reverb ②Hall reverb ③Arena reverb ④Delay ⑤Delay+Reverb ⑥Shimmer ⑦Harmonizer A ⑧Harmonizer B
XL Mic transmitter
Dimensions
60mm(L)*25mm(W)*10mm(H)
Net Weight
38g
Mic Type
Condenser mic
Transmit bandwidth
2.4GHz global ISM, smart automatic frequency hopping
Frequency response
Normal mode: 20Hz~20KHz,+1dB/-3dB
Range boost: 20Hz~16KHz,+1dB/-3dB
Polar pattern
Cadioid
Max SPL
140dB
THD +N
Less than 0.05% (1KHz@-10dB FS)
Battery Life
5~7 hours
*Retain 80% of maximum capacity after 300 recharging cycles
Sensitivity
0dB/+3.5dB/+6dB
Contents
Main box
PRIME mic transmitter
PRIME stage receiver
Advanced Spring Clip*1
Wind cap*3
Sponge hook*2
Wind clip*5
Velcro belt*1
Velcro adhesive*1
Quick start guide
Micro USB charging cable for mic transmitter
Accessory package
Antenna 2.0
USB DC power adaptor
Power supply cable for receiver
6.3mm TS cable
6.3mm 1/4” male to 3.5mm female audio adaptor
6.3mm balanced TRS to XLR adapter
